Desander is widely used for the purification and recycling of slurry in the construction of hydropower, continuous concrete wall, slurry shield tunnel, etc. The equipment is increasingly becoming a necessity of civil engineering construction since it not only can cut down construction cost, but also can reduce the pollution of the environment.
Hydrocyclone Drilling Mud Slurry Water Sand Separation Cyclone Desander
Main Applications:
* By fully purifying slurry, it is favorable to control slurry index, reduce drill sticking phenomena, and improve drilling quality.
* By thoroughly separating the slag and soil, it is favorable to enhance drilling efficiency.
* By realizing the repetition use of slurry, it can save slurry making materials and thus reduce the construction cost.
* By adopting the technique of close-cycle purification and low water content of removed slag, it is favorable to reduce environmental pollution.
DESANDER DATA
|
Model |
JT - 20/30
|
JT-50/30
|
JT- 100/30JT |
- 200/60 |
JT - 250/30 |
JT - 250/45 |
JT - 250/60 |
| Slurry feed capacity |
20m3/h
|
50m 3/h |
100m3/h |
200m3/h |
250m 3/h |
250m 3/h |
250 m 3/h |
| Cut point |
30 μm
|
50 μm |
30 μm |
60 μm |
30 μm |
45 μm |
60-20 μm |
| Soild feed capacity |
10 t/h
|
10-26t/h |
25-50t/h |
25-80t/h |
25-80 t/h |
25-80 t/h |
25-80 t/h |
| Total capacity |
9.7 kw
|
17.2kw |
24.2kw |
48 kw |
58-60.8 kw |
58-60.8 kw |
58-60.8 kw |
|
Weight |
1700kg
|
2100kg |
2700kg |
4800kg |
4900-7600kg |
4900-7600kg |
4900-7600kg |
