Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction

1
MOQ
2000~20000$
Price
Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction
Features Gallery Product Description Request A Quote
Features
Specifications
Material: 35CrMo,Q345,Cr-Mo
Product Name: Casing Pioe
Outer Diameter:: 620 - 2500 Mm, 620 - 2500 Mm
Name: Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction
Highlight:

drilling rig pipe casing joints

,

forged casing joints

,

double wall casing joints
Basic Infomation
Place of Origin: China
Brand Name: JTHL
Certification: ISO9001
Model Number: casing -1
Payment & Shipping Terms
Packaging Details: customer
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000/month
Product Description



D1/D2 t1 t2 d t3 JL0S Single walled casing tube JL0D Double walled casing tube
mm Weight[kg] Working length(mm) Weight[kg] Working length(mm)
1m 2m 3m 4m 5m 6m 8m 1m 1m 3m 3m 5m 6m 8m
600/520 15 12 10 20 380 672 993 1255 1546 1838 2421 433 805 1177 1660 2060 2450 3230
6403/560 15 12 10 20 409 720 1032 1345 1657 1959 2593 465 862 1259 1780 2200 2620 3450
700/620 15 12 10 20 117 789 1131 1173 1815 2157 2811 509 945 1381 190 2420 2850 3800
750/670 15 12 10 20 481 848 1215 1582 1949 2316 3050 549 1019 1489 2110 2600 3100 41090
800/720 15 15 8 20 514 905 1298 1690 2082 2474 3258 587 1090 1593 2430 3010 3600 4760
880/800 15 15 8 20 566 998 1430 1862 2294 2726 3590 637 1179 1720 2680 3330 3970 5260
900/820 l5 15 8 20 580 1022 1464 1906 2348 2790 3674 653 1206 1759 2750 3410 4070 5380
1000/920 15 15 8 20 640 1133 1626 2119 2612 3105 4091 724 1343 1962 3060 3800 4540 6010
1080/1000 15 15 8 20 690 1190 1720 2260 2820 3350 4420 790 1440 2155 3320 4110 4910 6510
1180/1100 15 15 8 20 760 1350 1925 2510 3100 3680 4840 860 1590 2340 3640 4510 5390 7130
1200/1120 l5 5 8 25 860 1600 2340 3080 3820 4560 6030 870 1620 1365 3700 1590 5480 7260
1300/1220 15 15 8 25 945 1745 2545 3375 1150 4950 6550 950 1770 2480 4020 4990 5960 7890
1500/1400 15 15 18 25 1440 2370 3300 4230 5160 6090 7950 1485 2520 3555 5140 6325 7510 9880
1800/1700 20 20 8 25 1720 2830 3950 5070 6190 7310 9550 1910 3505 5085 7380 9165 10950 14520
2000/1880 20 20 18 25 2190 3430 4670 5910 7150 8390 10870 2530 4000 6670 8820 10900 12990 17110



1. The technical parameters and processes of the products are in line with the Euro standard

2. Deformation and accuracy is strictly controlled through heat treatment , each casing is interchangeable.

3.Besides Bauer , casing is also suitable for Soilmec , Casagrande and China brand rig such as Sany XCMG etc.

Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction 0Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction 1

Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction 2Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction 3Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction 4



Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction 5

Drilling Rig Pipe Casing Joints Forged Double Wall For Foundation Construction 6
